SAMSUN SMART PRO 2500VA/24V

Samsun SMART PRO 2500VA/24V Pure Sine Wave UPS

The Samsun SMART PRO 2.5KVA/24V Pure Sine Wave UPS is a high-performance uninterruptible power supply (UPS) system designed to provide reliable backup power for homes and businesses. It features advanced battery charging technology, complete protection mechanisms, and a user-friendly interface. The UPS is ideal for sensitive electronic equipment due to its pure sine wave output, ensuring stable and clean power delivery.

Key Features

1. Pure Sine Wave Output

   • Ensures compatibility with sensitive electronics (e.g., computers, medical equipment, and appliances).

   • Output voltage: 220V ± 5% or 10% | Frequency: 50 Hz ± 1%.

2. Dual Mode Operation

   • UPS Mode:

     • Low cut: 175V ± 10V | Recovery: 185V ± 10V.

     • High cut: 265V ± 10V | Recovery: 255V ± 10V.

     • Fast changeover time: < 10 ms.

   • WUPS Mode (Wide Voltage Range):

     • Low cut: 90V ± 10V | Recovery: 110V ± 10V.

     • High cut: 295V ± 10V | Recovery: 285V ± 10V.

     • Changeover time: < 30 ms.

3. Advanced Battery Charging

   • Independent charger with adjustable current:

     • 12A ± 1A (for 100Ah–135Ah batteries).

     • 15A ± 1A (for 150Ah–200Ah batteries).

   • Boost voltage settings:

     • 14.0V ± 0.2V per battery (LA/Flooded).

     • 14.5V ± 0.2V per battery (SMF/Tubular).

4. Battery Protection

   • Low battery warning: 11V ± 0.2V per battery.

   • Low battery cut-off: 10.8V ± 0.2V per battery.

5. Robust Design

   • Operates in temperatures: 0°C to 50°C.

   • Storage temperature: 0°C to 50°C.

   • Humidity tolerance: 0–95% RH (non-condensing).

6. Safety & Reliability

   • Protects against backfeed and phase-to-phase faults.

   • Overload capacity: > 100%.

7. User-Friendly Interface

   • Easy monitoring and control with clear indicators.
