SAMSUN SMART PRO 5000VA/48V
Choose options
- Model:Smart Pro Series
- Rated Capacity:5000 VA
- DC Input Voltage:48V DC
- Battery Configuration:4 x 12V batteries (100Ah to 220Ah)
- Input Voltage Range (UPS Mode):175V - 265V ± 10V
- Input Voltage Range (WUPS Mode):90V - 285V ± 10V
- Input Frequency Range:40Hz - 60Hz
- Output in Mains Mode:Same as Input (Voltage & Frequency)
- Bulk Absorption Voltage:59.2V ± 0.4V
- Float Charging Voltage:54.8V ± 0.4V
- Boost Voltage (LA Battery):56.0V ± 0.4V
- Boost Voltage (Tubular/SMF):58.0V ± 0.4V
- Charging Current (100Ah-220Ah):20A - 25A
- Deep Discharge Recovery:Yes (Independent Charger)
- Output Voltage:220VAC +5% -10%
- Output Frequency:50Hz ± 0.2 Hz
- Output Waveform:Pure Sine Wave (≤ 5% THD)
- Full Load Discharging Current:74A ± 2A
- No-Load Current:≤ 4% of rated capacity
- Changeover Time (UPS Mode):< 4 ms
- Changeover Time (WUPS Mode):< 25 ms
- Low Battery Warning:42.7V ± 0.4V
- Low Battery Cut-off:42.4V ± 0.4V
- Overload Protection:Yes (Indication at 101% load)
- Short Circuit (Backup):System shutdown after 3 retries
- Short Circuit (Mains):Mains MCB Trip
- Back Feed Protection:System Shutdown (No retry)
- Over Temperature:Shutdown at >100°C Heat Sink Temp
- Reverse Battery Polarity:Battery MCB Trip
- Display:Comprehensive LED Status Display
- Alarms:Audible Buzzer for all fault conditions
The Samsun Smart Pro 5000/48V is a high-capacity Pure Sine Wave Home UPS engineered to provide robust and intelligent backup power for medium to large homes and small offices. Designed to ensure you "Never Feel Powerless," it delivers clean, stable power essential for protecting sensitive electronics like air conditioners, computers, and home appliances. A key highlight is its Independent Charger for Deep Discharge Battery Recovery, which can revive completely drained batteries, enhancing their longevity. With a high 25A charging current, dual operating modes (UPS/WUPS), and comprehensive protection features, this 5kVA system offers a reliable and user-friendly solution for managing power outages and voltage fluctuations.
Key Features & Benefits
-
Pure Sine Wave Output:
-
Generates a clean and stable sine wave, identical to grid power, ensuring the safe and efficient operation of all sensitive electronics, including ACs, medical equipment, and LED TVs, without risk of damage.
-
-
Deep Discharge Battery Recovery:
-
Features an independent charger specifically designed to recover deeply drained batteries that other inverters cannot, potentially saving significant costs on battery replacements and extending battery life.
-
-
High-Speed 25A Charging:
-
A powerful 25A charger ensures faster replenishment of large battery banks (up to 220Ah), reducing grid dependency and quickly restoring backup capacity after prolonged outages.
-
-
Dual-Mode Operation (UPS & WUPS):
-
Offers a UPS mode for standard voltage areas (175V-265V) with an ultra-fast <4ms switchover, and a WUPS mode for areas with severe fluctuations (90V-285V), providing versatile protection for all grid conditions.
-
-
Comprehensive System Protection:
-
Built with multi-layered safety features including protection from back feed, phase-to-phase faults, overload, short circuit (with retries), over-temperature, and reverse battery polarity, safeguarding both the user and the equipment.
-
-
User-Friendly Interface and Alarms:
-
A detailed LED status display provides real-time information on all parameters (voltage, frequency, load %, etc.), while an audible buzzer gives immediate alerts for any faults like overload or low battery.
-
-
Optimized for Large Battery Banks:
-
Designed to support a 48V system with four 12V batteries ranging from 100Ah to 220Ah, making it suitable for applications requiring extended backup hours and higher power demand.
-
-
Robust Build and High Efficiency:
-
Constructed with a high-quality heatsink and efficient circuitry, it maintains low no-load consumption (≤4%) and reliable performance even under demanding conditions.
-
