SAMSUN ALPHA 2500VA/24V INVERTER
SAMSUN ALPHA 2500VA/24V INVERTER
SAMSUN ALPHA 2500VA/24V INVERTER
SAMSUN ALPHA 2500VA/24V INVERTER

SAMSUN ALPHA 2500VA/24V INVERTER

AED 0.00

Shipping calculated at checkout

Power Capacity  : 2.5kva/24v
Product Weight  : 21.220 Kgs
Colour Name  : Black/White
Dimension in cm  : 49.5 x 30 x 38
Number of pieces  : 1BOX
Origin  : Made in INDIA
Product Overview
Highlights
  • Model:Alpha Series 2.5kVA/24V
  • Output Power:2.5kVA / 2000W (at Power Factor 0.8)
  • Output Voltage & Frequency:230V AC ± 3%, 50Hz
  • Output Waveform:Pure Sine Wave (<1% Total Harmonic Distortion)
  • Battery Voltage:24V DC
  • Mains Input Voltage:230V AC, 50Hz (Operational Range: 0V - 270V)
  • Battery Charging Current:Adjustable from 1A to 15A
  • Cooling Fan Operation:Auto ON at 70°C / Auto OFF at 60°C
  • Operating Temperature:0°C to 55°C
  • Storage Temperature:-15°C to 60°C
  • Humidity:5% to 95% RH (Non-Condensing)
  • Inverter Topology:MOSFET-based, Bridge Type
SAMSUN ALPHA 2500VA/24V INVERTER
Product Description

The Samsun Solar Alpha Series is a high-performance, solar-compatible uninterruptible power supply (UPS) and inverter system designed for both home and professional use. Engineered with a 100% copper coil for enhanced durability and efficiency, it delivers clean, pure sine wave output, making it perfectly safe for sensitive electronic equipment such as computers, laptops, medical devices, and LED TVs. Its robust design includes support for surge loads, lightning protection, and an intelligent battery management system, ensuring reliable power backup and protection in various conditions.

Key Features

  • Pure Sine Wave Output: Provides clean and stable AC power identical to grid power, ensuring the safety and longevity of connected sensitive electronics.

  • 100% Copper Coil: Offers superior conductivity, better heat resistance, higher efficiency, and longer operational life compared to aluminum coils.

  • Solar Compatible Design: Specifically engineered for seamless integration with solar panel systems, promoting energy independence and savings.

  • Intelligent 4-Stage Charger: Features (1) Bulk, (2) Absorption, (3) Float, and (4) Cut-off stages for optimized battery charging, health, and lifespan.

  • Advanced Display: LCD and LED indicators provide clear information on system status, input/output voltage, battery level, and fault alerts.

  • Surge Load Support: Capable of handling high instantaneous power demands from appliances like refrigerators, air conditioners, and water pumps.

  • Comprehensive Protections: Includes safeguards against Overload, Short Circuit, Deep Discharge, High/Low Voltage, and Lightning surges.

  • Wide Input Voltage Range: Operates reliably in areas with unstable grid power, accepting a very wide mains input range from 100V to 270V.
