SAMSUN ULTRA 1600 VA/12V PWM HYBRID INVERTER
SAMSUN ULTRA 1600 VA/12V PWM HYBRID INVERTER
SAMSUN ULTRA 1600 VA/12V PWM HYBRID INVERTER
SAMSUN ULTRA 1600 VA/12V PWM HYBRID INVERTER

SAMSUN ULTRA 1600 VA/12V PWM HYBRID INVERTER

AED 580.00

Shipping calculated at checkout

Product Weight  : 18.5 Kgs
Colour Name  : White/YellowGrey
Dimension in mm  : 425 x 315 x 355
Power Capacity  : 1600va/12v
Number of pieces  : 1BOX
Origin  : Made in INDIA
Product Overview
Highlights
  • Model:Ultra Series 1600VA/12V
  • Output Capacity:1600VA
  • Output Waveform:Pure Sine Wave
  • UPS Mode:Low Cut: 175V ±10V High Cut: 265V ±10V\t<10ms
  • WUPS Mode:Low Cut: 90V ±10V High Cut: 295V ±10V\t<30ms
  • Grid Charging Current:15A ±1A (factory setting)
  • Boost Voltage (LA/Flooded):14.0V ±0.2V per battery
  • Boost Voltage (Tubular):14.5V ±0.2V per battery
  • Solar Charger Type:PWM
  • Max Solar Input Voltage (Voc):25V per battery
  • Max PV Input Power:2000W
  • Max Charging Current:50A
  • Nominal Voltage:12V
SAMSUN ULTRA 1600 VA/12V PWM HYBRID INVERTER
Product Description

The Samsun Ultra Series 1600/12V is a PWM-based solar hybrid power conditioning unit (PCU) designed for residential and small-scale applications. It integrates solar power, grid electricity, and battery backup to provide reliable energy solutions in areas with unstable grid power. With a focus on cost-effectiveness, this model uses PWM (Pulse Width Modulation) technology for solar charging and delivers pure sine wave output to protect sensitive appliances. It supports 12V battery systems and is ideal for users seeking an affordable hybrid solar solution.

Key Features

PWM Solar Charging – Efficient and economical solar charging for basic energy needs.

Hybrid Operation – Seamlessly switches between solar, grid, and battery power.

Wide Voltage Range – Handles grid input from 90V to 295V (WUPS mode) for low-voltage areas.

Pure Sine Wave Output – Safe for sensitive electronics (e.g., laptops, refrigerators).

Battery Protection – Prevents over-discharge with low-voltage cutoffs and alarms.

User-Friendly LCD Display – Shows solar input, battery status, and system warnings.

Priority-Based Operation – Solar-first charging, with grid support when needed.

Compact Design – Space-efficient for home or small business use.

Operational Priorities

  • Solar Priority: Battery charges first from solar power.

  • Battery Priority: Uses solar energy primarily; switches to battery (up to 20% discharge) if solar is insufficient.

  • Grid Priority: Supports battery charging from the grid when solar is unavailable.

Ideal For:

  • Budget-conscious homeowners
  • Areas with frequent power cuts and low grid voltage
  • Basic solar hybrid systems with 12V batteries
  • Small shops and offices needing backup power
